    High Quality Gen4 I7 I5 I3 for Intel RPGA 947 Thin Mini-ITX HM86 Chipset DDR3L MAX 8G RAM Motherboard for AIO Computer AIO-HM86S39S-V1.0

    Ask Lasest Price
    Model Number : AIO-HM86S39S-V1.0
    Delivery Time : 5-8 working Days
    Supply Ability : 10000pcs/Day
    • Product Details
    • Company Profile

    High Quality Gen4 I7 I5 I3 for Intel RPGA 947 Thin Mini-ITX HM86 Chipset DDR3L MAX 8G RAM Motherboard for AIO Computer AIO-HM86S39S-V1.0


    High Quality Gen4 I7 I5 I3 for Intel RPGA 947 Thin Mini-ITX HM86 Chipset DDR3L MAX 8G RAM Motherboard for AIO Computer AIO-HM86S39S-V1.0

    Features (product features)

    Support Intel Gen4 I7, I5 and I3 series processors.

    Support 1 SATA interface, 2 USB3.0 and 7 USB2.0.

    Support single channel DDR3L 1600MHz SO-DIMM.

    Supports 5.1-channel ALC897 chip.

    Support 1 serial port

    High-speed USB3.0 interface transmission speed

    Mini PCIE expansion slot *2

    RJ45 Gigabit NIC interface

    Support VGA/HDMI/LVDS display interface, and support synchronous three displays.

    Support Windows7 and Windows10 32/64 bit operating systems.

    Support single power supply 12V~19V DC input.


    Model Name

    AIO-HM86S39S VER:1.0

    processor

    Intel Gen4 i7/i5/i3 series processors

    Southbridge

    HM86 Chipset

    memory

    technology

    Single channel DDR3L 1600MHz

    maximum capacity

    8GB

    Memory slot

    1*204Pin DDR3L SO-DIMM(Non-ECC)

    Post I/O

    DC interface

    1 standard 2.5mm DC power socket

    HDMI

    Standard D socket, supporting HDMI1.2.

    VGA

    Standard DB15 socket

    Ethernet

    1 Realtek Gigabit NIC

    Audio

    1 (Line-out, Mic-in)

    USB port

    4 (2 USB 3.0, 2 USB 2.0)

    Internal connector

    USB port

    5 (one FUSB can transfer out two USB2.0 interfaces);

    serial port

    1 (serial port only supports RS232 mode)

    power amplifier

    1*4Pin 2.0mm white socket, which can support up to two 5W2 speakers.

    JVGA

    Supports 1*12Pin pins (VGA and JVGA can only be selected)

    JHDMI interface

    Supports 2*8Pin pins (HDMI and JHDMI can only be selected).

    LVDS/EDP

    Support single (dual) channel 18(24) bits, (LVDS and EDP can only be selected)

    Mini-PCIe

    1 Mini PCIe slot with WIFI support.

    MSATA

    1 Mini PCIe slot with SSD hard disk support.

    serial ata

    1 7Pin SATA interface, supporting SATA 2.0

    PWR interface

    1 standard 2x2 Pin power socket

    Watchdog

    output

    system reset

    space

    Programmable for 1-255 seconds

    power consumption

    Maximum power

    Standby power consumption: 15.2W Full load power consumption: 85.5W

    environment

    temperature range

    working environment

    Storage environment

    Temperature:-10 ~ 60 Humidity: 5%~95%

    Temperature: -40~70 Humidity: 5%~95%

    DC power supply

    DC12V~19V power input

    Physical size

    measure

    170 mm x 170 mm
