    Industrial Intel 12th Generation Motherboard 45W AX12UP Intel Alder Lake Platform

    Intel 12th mainboard generation CPU 45W AX12UP V1.0 Intel Alder Lake platform industrial computer motherboard

    AX12UP is an industrial computer motherboard based on Intel.Alder LakeThe motherboard supports dual-channel memory, M.2(NGFF/NVME) and SATA mode SSD, RJ45, M.2-WIFI and M.2 5G different network access modes, and also supports rich peripheral interfaces to adapt to many different types of industrial computers in the industry.


    l Based on IntelAlder LakePlatform design

    l Support for Intel 12th generation processors

    l Support dual-channel SO-DIMM DDR4 memory

    l 1 × M.2 WIFI slot

    l 1 × M.2 5G slot

    l 1 × M.2 slot (supporting NGFF/NVME), 1× SATA

    l Post IO provides 2xUSB3.0.

    l Built-in pin can expand 8 USB2.0 interfaces.

    l 1 x HDMI-1.4A,1 x VGA,1 x LVDS,2x EDP

    l 6 x COM, 1 x LPT, 1 x PS2 keyboard and mouse

    l Support one-button clearing CMOS button function.

    l Support one-button reset button function.

    l Support DC12V power input


    Model Name

    AX12UP industrial computer motherboard.

    Motherboard chip

    IntelAlder Lake

    CPU

    Intel 12th generation CPU, TDP:45W

    Optional: I5-1245U, I5-1240P, I5-12500H.

    memory

    2*DDR4 SO-DIMM, 3200MHz/64G, single slot supports 32G at most.

    Cunzhu

    1*M.2 slot (supporting automatic switching of NGFF/NVME); 1*SATA 3.0 interface+1*SATA power interface

    Display interface

    1*HDMI-1.4A interface (optional with JHDMI), 1*VGA interface (optional with JVGA), 1*LVDS interface, 2*EDP interface.

    network

    2*RJ45 interface

    Network card chip

    Realtek RTL8111H Gigabit NIC Chip

    M.2 WIFI

    1*M.2 2230 slot (m.2 wifi);

    M.2 5G module

    1*M.2 slot (supports moving away 5G module)

    audio frequency

    1*Line out 1*MIC In 1*F_Audio built-in pin; 1*JAMP built-in power amplifier pin

    Audio chip

    Realtek ALC897 HD Audio Chip

    serial port

    6 serial ports: 2*9Pin serial port pin, 1*40Pin serial port pin, 2*3Pin serial port voltage pin, 2*3Pin serial port communication pin.

    6 serial ports all support RS232 mode, of which COM2 supports RS485 and RS422 mode, and COM3 supports RS485 mode.

    LPT interface

    1*LPT printer interface

    PS2 interface

    1*PS2 keyboard mouse interface

    Usb interface

    IO interface: 2*USB3.0

    Built-in pins: 4 sets of USB2.0 pins (8 USB2.0 ports can be expanded); 1*3Pin FUSB1 live jump cap

    LVDS function

    1*LVDS 30Pin pin, 1*6Pin display voltage jump cap (3.3V/5V/12V)

    LVDS supports replication/extended display.

    LVDS backlight function

    1*6Pin INVERTER interface, 1*3Pin screen backlight voltage jump cap (5V/12V), 1*3Pin backlight forward and backward jump cap.

    EDP function

    2*EDP 30Pin pin, 1*3Pin screen voltage jump cap (3.3V/5V/12V).

    Support copy/extended display

    EDP backlight function

    1*3Pin screen backlight voltage jump cap (5V/12V), 1*3Pin backlight positive and negative jump cap.

    GPIO

    Support 8-way bidirectional 3.3V

    onekey recovery

    Support one-button reset button

    Functional pin

    1*FPANEL panel pin; 1*4Pin CPU fan; 1*3Pin SYS fan

    Power input

    1*DC socket; 1*4Pin built-in power socket (DC12V power input)

    product size

    Thin Mini-ITX motherboard specification, 170 x 170 mm x 6L

    Working temperature

    -10~60

    Working humidity requirements

    10%~90% without condensation

    Storage temperature

    -25~70

    power consumption

    Standby power consumption: 17W Full load power consumption: 63W

    other

    1 JCMOS jump cap; 1*3Pin JAT jump cap; 2*5Pin diagnostic card interface
