    H81 Chipset Lga 1150 AIO DDR3 Intel 4th GEN Motherboard AIO-H81S39M-V1.0

    Ask Lasest Price
    Model Number : AIO-H81S39M-V1.0
    Delivery Time : 5-8 working Days
    Supply Ability : 10000pcs/Day
    • Product Details
    • Company Profile

    H81 Chipset Lga 1150 AIO DDR3 Intel 4th GEN Motherboard AIO-H81S39M-V1.0

    Intel 4th GEN lga1150 AIO motherboard AIO-H81S39M-V1.0


    Features (product features)

    ▲ Support Intel 4th generation Celeron, Pentium, I3, I5, I7 series processors, LGA1150 socket.

    ▲ Support a 204-pin SO-DIMM 8GB DDR3/1600MHz memory slot.

    ▲ Support 2 SATA interfaces and 1 M.2 hard disk.

    ▲ Support 2 USB3.0 and 6 USB2.0.

    ▲ Supports 5.1-channel ALC897 sound card chip.

    ▲ Support 1 serial port and RS232 mode.

    ▲ Support 1 WIFI/4G module.

    ▲ Support one RJ45 Gigabit NIC interface.

    ▲ Support VGA/HDMI/LVDS display interface, and support synchronous dual display.

    ▲ Support Win7/Win10 32/64 bit operating system and Linux system.


    Model Name

    AIO-H81S39M Ver:1.1

    processor

    Intel 4th Generation Celeron, Pentium, I3, I5 and I7 Series Processors

    Southbridge

    H81 Chipset

    memory

    technology

    Single channel DDR3 1600MHz

    maximum capacity

    8GB

    Memory slot

    1 204 Pin DDR3 SO-DIMM(Non-ECC) memory slot

    Post I/O

    power source

    1 standard 2.5mm DC power socket, supporting DC12V~19V input.

    HDMI

    Provide one standard D socket.

    VGA

    Standard DB15 socket

    Ethernet

    1 Realtek Gigabit NIC

    Audio

    1 (Mic-in, Line-out)

    USB port

    2 USB 3.0, 2 USB2.0

    Internal connector

    USB port

    4 (one FUSB can switch out two USB2.0 interfaces)

    serial port

    1 (RS232 mode only)

    power amplifier

    1*4Pin black socket, supporting up to 2 speakers with 5W2.

    F_Audio

    1 2*5Pin pin (Mic-in, Line-out)

    serial ata

    2 SATA interfaces, and provide 2 1*4Pin power supply interfaces (1 SATA2.0 and 1 SATA3.0).

    LVDS interface

    Support single (dual) channel 18(24) bits

    JVGA

    1*12Pin pin (VGA and JVGA can only be selected)

    M.2

    Support NVME/NGFF M.2 hard disk.

    Mini PCIe

    Support WIFI/4G module

    PWR interface

    1 2*2Pin power socket, supporting DC12V~19V input.

    power consumption

    Maximum power

    Standby power consumption: 11.4W Full load power consumption: 98.8W w.

    environment

    temperature range

    working environment

    Storage environment

    Temperature:-10 ~ 70℃ Humidity: 5%~95%

    Temperature: -40~70℃ Humidity: 5%~95%

    DC power supply

    DC12V~19V power input

    Physical size

    measure

    170 mm x 170 mm
