Mini ITX N100 Motherboard 1LAN 12th Gen 1*Com DDR4 Max 32GB M.2 SSD

    Buy cheap Mini ITX N100 Motherboard 1LAN 12th Gen 1*Com DDR4 Max 32GB M.2 SSD from wholesalers

    Buy cheap Mini ITX N100 Motherboard 1LAN 12th Gen 1*Com DDR4 Max 32GB M.2 SSD from wholesalers
    • Buy cheap Mini ITX N100 Motherboard 1LAN 12th Gen 1*Com DDR4 Max 32GB M.2 SSD from wholesalers
    • Buy cheap Mini ITX N100 Motherboard 1LAN 12th Gen 1*Com DDR4 Max 32GB M.2 SSD from wholesalers
    • Buy cheap Mini ITX N100 Motherboard 1LAN 12th Gen 1*Com DDR4 Max 32GB M.2 SSD from wholesalers

    Mini ITX N100 Motherboard 1LAN 12th Gen 1*Com DDR4 Max 32GB M.2 SSD

    Ask Lasest Price
    Model Number : AIO-N100-V1.1
    Payment Terms : T/T
    Supply Ability : 10000pcs/Day
    Delivery Time : 5-8 working Days
    • Product Details
    • Company Profile

    Mini ITX N100 Motherboard 1LAN 12th Gen 1*Com DDR4 Max 32GB M.2 SSD

    N100 Motherboard 1LAN 12th Gen Alder Lake-N 1*Com DDR4 max32GB M.2 SSD Mini ITX Motherboard mother board for all in one pc


    Model nameAIO-N100 V1.0
    Motherboard chipIntelAlder Lake-N
    CPUIntel N serial CPU,TDP:6W
    Could use N100/N200/N300/N305 and so on
    internal storage1*DDR4 SO-DIMM,3200MHz/32G, 1 ram max Support 32G
    Cunzhul 1*M.2Slot(NGFF/NVMEautomaticly shift)
    Display interface2*HDMI 1.4 slot,1*DPslot(Support3840*2160 60Hz resolution)
    network2*RJ45 slot
    Network card chipRealtek RTL8111H 1000M Giga lan chipset
    WIFI1*M.2 2230Slot(M.2 WIFI)
    audio frequency1*Line_out,1*MIC_In
    Audio chipRealtek ALC897 high audio chipset
    serial port1*DB9 COM((inner COM optional)
    Usb interfaceIO slot:1*USB3.0; 4*USB2.0; 1 x TYPE-C
    Functional pin1*FPANEL pin; 1*4Pin CPU fan
    Power input1*DC slot; 1*4Pin inside power supply(DC12V~19Vpower input)
    product sizeThin Mini-ITX,120 x 120 mm x 8L
    Working temperature-10℃~60℃
    Working humidity requirements10%~90%
    Storage temperature-40℃~70℃
    power consumptionStandby power wattage:5.7Wfull load power wattage:28.5W
    other1*JCMOS bottom; 1*3Pin JAT jumper; 2*5Pin debug card slot; 1*power on/off slot; 1*power LED,HDD LED
