    Hard Drive Embedded Motherboard Jasper Lake N5095 CPU SATA Industrial IoT IIoT

    Ask Lasest Price
    Model Number : AIO-N5095 V1.3
    Delivery Time : 5-8 working Days
    Supply Ability : 10000pcs/Day
    • Product Details
    • Company Profile

    Hard Drive Embedded Motherboard Jasper Lake N5095 CPU SATA Industrial IoT IIoT

    Motherboard Jasper Lake N5095 CPU SATA Hard Drive Interface Mainboard


    AIO-N5095S49M all-in-one motherboard, based on Intel.Celeron-N series The processor and motherboard support single-channel memory, SATA, M.2(NGFF/NVME) mode SSD, RJ45/M.2 WIFI different network access modes, and also support rich peripheral interfaces to adapt to many different types of all-in-one machines in the industry.


    l Based on Intel Jasper Lake Platform design

    l Support Intel Celeron-N series processor

    l Support single-channel SO-DIMM DDR4 memory

    l 1× M.2 2230 slot (supporting M.2 WIFI)

    l 1× M.2 2280/2240 slot (supporting NGFF/NVME mode)

    l The rear IO provides 4xUSB3.0.

    l Built-in pin can expand 3 USB2.0 interfaces.

    l 1 x HDMI ,1 x VGA ,1 x LVDS

    l 1 x COM

    l 1 x Gigabit network card, supporting PXE and network wake-up function.


    Model Name

    AIO-N5095 VER:1.3

    processor

    Intel Jasper Lake N Series Processor (N5095)

    memory

    technology

    Single channel DDR4 2933MHz

    maximum capacity

    Supports up to 16GB of memory.

    Memory slot

    1*260Pin DDR4 SO-DIMM(Non-ECC)

    Post I/O

    DC power supply

    1 standard 2.5mm DC power socket, supporting DC12V~19V input.

    HDMI

    Standard D socket, supporting HDMI1.2.

    VGA interface

    Standard DB15 socket

    USB port

    4 USB3.0 interfaces

    Ethernet

    1 Gigabit network card, Realtek network card chip

    Post Audio

    1 (Mic-in, Line-out)

    Internal connector

    LVDS interface

    Support single (dual) channel 18(24) bits

    JVGA

    1*12Pin pin (VGA and JVGA can only be selected)

    serial port

    1 (RS232 mode only)

    USB port

    2 (one FUSB can transfer out two USB2.0 interfaces)

    Mini PCIe

    Support WIFI/4G module

    MSATA

    Support MSATA hard disk

    FAudio

    1 2*5Pin front audio pin (Mic-in, Line-out)

    power amplifier

    1*4Pin 2.0mm black socket, which can support up to two 5W2 speakers.

    serial ata

    1 7Pin SATA interface and 1 4Pin power socket, supporting SATA3.0.

    FAN

    2 (1 SYS_FAN;; 1 CPU_FAN)

    PWR interface

    1 2*2Pin power socket, supporting 12V~19V input.

    JESPI interface

    1 2*5Pin JESPI debugging interface

    environment

    temperature range

    working environment

    Storage environment

    Temperature:-10 ~ 60℃ Humidity: 5%~95%

    Temperature: -40~85℃ Humidity: 5%~95%

    DC power supply

    DC12V~19V power input

    Physical size

    measure

    170 mm * 170 mm
