    Desktop Custom Motherboard Ddr4 I9 Cpu HM570 Chipset With Processor I9-11950h

    Ask Lasest Price
    Model Number : ATX-HM570 VER:1.0
    Delivery Time : 5-8 working Days
    Supply Ability : 10000pcs/Day
    • Product Details
    • Company Profile

    Desktop Custom Motherboard Ddr4 I9 Cpu HM570 Chipset With Processor I9-11950h

    Desktop Mainboard Ddr4 I9 Cpu HM570 Gaming Motherboard With Processor I9-11950h

    Features (product features)

    ▲ Support Intel Tiger Lake I3, I5 and I7 series processors.

    ▲ Support 4 SATA_3.0 interfaces.

    ▲ Dual-channel DDR4 memory, with maximum support of 64GB 3200MHz.

    ▲ Support 1 front Audio.

    ▲ Support one serial port and only RS232 mode.

    ▲ Support 6 USB3.0 and 4 USB2.0.

    ▲ Support 1 WIFI module.

    ▲ Support M.2 KEYE

    ▲ Support one RJ45 Gigabit NIC interface.

    ▲ Support VGA/HDMI/DP display interface, and support synchronous three displays.


    Model Name

    ATX-HM570 VER:1.0

    processor

    Intel Tiger Lake I3, I5, I7 series processors

    Southbridge

    HM570 Chipset

    memory

    technology

    Dual-channel DDR4 3200MHz

    maximum capacity

    64GB

    Memory slot

    2*260Pin DDR4 DIMM(Non-ECC)

    Post I/O

    USB_PS/2

    Two USB2.0 interfaces and one one-to-two PS/2 interface

    HDMI interface

    1 standard D-socket, supporting HDMI2.0, and the maximum supporting resolution is 3840*2160@30Hz.

    DP interface

    1 standard D-socket, with the maximum supported resolution of 3840*2160@60Hz.

    VGA interface

    1 standard DB15 socket

    USB30

    4 USB3.0 interfaces

    Ethernet

    1 Gigabit network card, Realtek network card chip

    Post Audio

    1 (Mic-in, Line-out, Line-in)

    Internal connector

    Audio

    1 2*5Pin pin audio interface (Mic-in, Line-out)

    serial port

    1 (serial port only supports RS232 mode)

    JESPI

    1 2*5Pin pin diagnostic card interface

    Usb interface

    4 USB (one can turn out 2 USB3.0; One USB2.0 interface that can be turned out)

    M.2

    1 full-length M.2 slot, supporting SATA-M.2 hard disk.

    Mini PCIe

    1 module supporting M.2-WIFI

    PCIE

    1 PCIE_X16; 1 PCIE_x1

    serial ata

    4 SATA interfaces, supporting SATA 3.0

    ATXPWR interface

    1 standard 1x8Pin power socket; 1 standard 1x24Pin power socket

    environment

    temperature range

    working environment

    Storage environment

    Temperature:-10 ~ 60℃ Humidity: 5%~95%

    Temperature: -40~85℃ Humidity: 5%~95%

    Physical size

    measure

    216 mm * 175 mm
