Model Number : | B250-AI-VX |
Delivery Time : | 5-8 working Days |
Supply Ability : | 10000pcs/Day |
12GPU server motherboard for bitcoin crypto mainboard B250-AI-VX
Features (product features)
▲ Support Intel 6,7,8,9th Corei7/i5/i3 Celeron/Pentium LGA1151 pin series processors.
▲ Support 1 * PCIe 3.0x16; 11* PCIe X1
▲ Support maximum memory of 32G and dual-channel DDR4.
▲ Support HDMI & VGA&DVI simultaneous three displays.
▲ Support 1 Gigabit NIC interface.
▲ Support 6 USB3.0 and 4 USB2.0.
▲ Support supports 1*MSATA+4*SATA.
▲ Support 3+2 phase CPU power supply.
Model Name | B250-AI-V2.1 | ||
processor | Intel 6,7,8,9th Corei7/i5/i3 Celeron/Pentium LGA1151 Pin Series Processors | ||
Southbridge | B250 Chipset | ||
memory | technology | Dual channel DDR4 | |
maximum capacity | 32GB | ||
Memory slot | 2 x 288 PIN DDR4 | ||
Post I/O | PS/2 | 1 (1 KB interface and 1 MS interface) | |
Ethernet | 1 gigabit network card, RTL8111GUS-CG chip. | ||
USB port | 4 USB 3.0 | ||
Display interface | HDMI & VGA & DVI | ||
Internal connector | CFAN | 1 1*4PIN pin | |
SFAN | 2 1x3Pin pins | ||
JLPC | 1 x 2x5Pin pin | ||
JCOM | one | ||
USB2.0 | 4 USB2.0 (1 FUSB can be transferred out of 2 USB) | ||
Jaudio | 1 x 2x5Pin pin | ||
USB3.0 | 2 USB3.0 (1 FUSB can be transferred out of 2 USB) | ||
M-SATA | 1 x M-SATA SLOT(SATA3.0) | ||
SATA | 4 (SATA3.0) | ||
Big 4PIN | one | ||
PCIe | Article 12 (1 * PCIe X16 3.0; 11* PCIe x1 3.0) | ||
environment | temperature range | working environment | Storage environment |
Temperature: 0 ~ 50 C Humidity: 5%~95% | Temperature:-20 ~ 70 C Humidity: 5%~95% | ||
Physical size | measure | 185 mm x 240 mm |
![]() |
