    Industrial OPS Mini PC Mainboard With Intel HM77 Express Chipset OPS23-V1.0

    Ask Lasest Price
    Model Number : OPS23-V1.0
    Delivery Time : 5-8 working Days
    Supply Ability : 10000pcs/Day
    • Product Details
    • Company Profile

    Industrial OPS Mini PC Mainboard With Intel HM77 Express Chipset OPS23-V1.0


    Factory Customization Product Industrial OPS Mini PC With Intel HM77 Express Chipset for Mainboard Computer Pc OPS23-V1.0


    Features (product features)

    Support Intel Sandy Bridge/Ivy Bridge series processors.

    Support DDR3 memory, up to 16GB and 1600 MHz SDRAM.

    Support stereo dual-channel ALC887 chip sound card.

    Support 1 serial port; Support 1 RJ45 Gigabit NIC interface.

    Support 3 USB3.0 and 9 USB2.0.

    Support 1 7Pin SATA interface and 1 MSATA interface.

    Support 1 Mini PCIE expansion slot (including 8pin SIM card slot) and support WIFI/4G Module.

    Support system one-click backup and restore function.

    Support 1 rear VGA interface, 1 rear HDMI interface, 1 expansion daughter card HDMI interface /DP interface, and support synchronous dual display.

    Support 19V/12V DC power input.

    Support Windows7, Windows10 32/64 bit and Linux operating system.


    Model Name

    OPS23 VER:1.1

    processor

    Intel Sandy Bridge/Ivy Bridge series processors (such as I3-2310M, I5-3230M CPU)

    Southbridge

    HM77

    memory

    technology

    Single channel DDR3 1600MHz

    maximum capacity

    16GB

    Memory slot

    1 x 204Pin DDR3 SO-DIMM(Non-ECC)

    Post I/O

    onekey recovery

    1 one-button reset button

    HDMI

    Standard D socket, supporting HDMI1.2, maximum resolution: 2560*1600@60Hz.

    VGA

    Standard DB15 socket, the maximum supported resolution is 2560*1600@60Hz.

    Ethernet

    1 RJ45 gigabit network card, RTL8111F network card chip.

    USB

    2 USB3.0 interfaces and 4 USB2.0 interfaces.

    Audio

    1 (Mic-in, Line-out)

    switching push-button

    1 switch button

    Indicator light

    1 power indicator and 1 hard disk indicator

    Internal connector

    USB

    1 USB2.0 interface with 2*5Pin pin spacing of 2.0mm (one FUSB can switch out two USB2.0 interfaces).

    serial port

    1 serial port, supporting RS232 mode

    Audio

    1 2*5Pin pin (Mic-in, Line-out)

    Mini-PCIe

    1 Mini PCIe slot, supporting WIFI and 4G modules.

    MSATA

    Support MSATA hard disk, support SATA3.0 speed.

    serial ata

    1 7Pin SATA interface supporting SATA 2.0 speed.

    power source

    1 standard 2.5mm 19V/12V DC power socket; One 2x2Pin ATX power outlet is optional.

    Extended daughter card

    USB

    Expandable 1 USB3.0 interface and 3 USB2.0 interfaces.

    HDMI

    One HDMI interface can be extended, supporting HDMI1.2, and the maximum resolution is 2560*1600@60Hz, so you can choose between extended DP.

    DP

    One DP interface can be extended, and the maximum resolution is 2560*1600@60Hz, so you can choose between extended HDMI.

    power source

    1 standard 2.5mm 19V/12V DC power socket; 1 x 2x2Pin ATX power socket

    Audio

    1 Line-out

    Watchdog

    output

    system reset

    space

    Programmable for 1-255 seconds

    power consumption

    Maximum power

    Standby power consumption: 15.6W Full load power consumption: 57.0W w.

    environment

    temperature range

    working environment

    Storage environment

    Temperature:-40 ~ 70 Humidity: 5%~95%

    Temperature: -40~85 Humidity: 5%~95%

    Physical size

    measure

    170 mm x 190 mm
