    Mini ITX Industrial Embedded Motherboard NANO Itx 2 LAN Motherboard CPU VGA HDM Display

    Ask Lasest Price
    Model Number : AX2-N8U2L-V1.1
    Delivery Time : 5-8 working Days
    Supply Ability : 10000pcs/Day
    • Product Details
    • Company Profile

    Mini ITX Industrial Embedded Motherboard NANO Itx 2 LAN Motherboard CPU VGA HDM Display

    Industrial Mini-ITX motherboard NANO Itx 2LAN Motherboard Support Intel Alder Lake-N N100 AX2-N8U2L-V1.1 CPU VGA HDM Display


    AX2-N8U2L is an industrial control motherboard based on Intel.Alder Lake-NThe motherboard supports single channel memory, M.2(NGFF/NVME), different network access modes of RJ45/M.2 WIFI module, and rich peripheral interfaces, which are suitable for many different types of industrial computers in the industry.


    l Based on IntelAlder Lake-NPlatform design

    l Support n series Intel processors

    l Support single-channel SO-DIMM DDR4 memory

    l 1× M.2 2230 slot (supporting M.2 WIFI)

    l 1 M.2 2280 slot (supporting NGFF/NVME automatic switching)

    l The rear IO provides 1xUSB3.0, 4xUSB2.0 and 1x Type-C.

    l 2 x HDMI,1 x DP

    l 2 x gigabit network card, supporting PXE and network wake-up function

    l Support DC12V~19V power input

    l Windows S10, Windows S11 and Linux are supported.


    Model Name

    AX2-N8U2L-V1.1

    Motherboard chip

    IntelAlder Lake-N

    CPU

    Intel n-series CPU, TDP: 6W

    Optional: N100; N200 N300 N305 and so on

    memory

    1*DDR4 SO-DIMM, 3200MHz/32G, single slot supports 32G at most.

    Cunzhu

    1*M.2 slot (NGFF/NVME automatic switching)

    Display interface

    2*HDMI 1.4 interface, 1*DP interface (supporting 3840*2160 60Hz resolution)

    network

    2*RJ45 interface

    Network card chip

    Realtek RTL8111H Gigabit NIC Chip

    WIFI

    1*M.2 2230 slot (M.2 WIFI)

    audio frequency

    1*Line_out; 1*MIC_In

    Audio chip

    Realtek ALC897 HD Audio Chip

    Usb interface

    IO interface: 1 * USB 3.0; 4*USB2.0 1 x Type-c

    Functional pin

    1*FPANEL panel pin; 1*4Pin CPU fan

    Power input

    1*DC socket; 1*4Pin built-in power socket (DC12V~19V power input)

    product size

    Thin Mini-ITX motherboard specification, 120 x 120 mm x 8L

    Working temperature

    -10~60

    Working humidity requirements

    10%~90% without condensation

    Storage temperature

    -40~70

    power consumption

    Standby power consumption: 5.7W Full load power consumption: 28.5W

    other

    1 JCMOS button; 1*3Pin JAT jump cap; 2*5Pin diagnostic card interface; 1* Switch button; 1* Power LED, hard disk LED
