    Nano ITX Industrial Embedded Motherboard 12x12cm J1900 Fanless Mini Computer Mainboard

    Ask Lasest Price
    Model Number : GW2-N19D-V1.2
    Delivery Time : 5-8 working Days
    Supply Ability : 10000pcs/Day
    • Product Details
    • Company Profile

    Nano ITX Industrial Embedded Motherboard 12x12cm J1900 Fanless Mini Computer Mainboard


    Nano ITX Motherboard 12 * 12cm J1900 Cassette Computer Motherboard Fanless Industrial Computer Minicomputer


    Features

    ▲ Support Intel Bay Trail-M/D serial processor

    ▲ Support DDR3L Memorry ,MAX Support 8GB 1333MHz SDRAM

    ▲ Support Stereo Dual-Channel ALC887 Audio Codec with Onboard Amplifier

    ▲ Support 2*COM slot

    ▲ Support 1*USB3.0,5*USB2.0

    ▲ Support MSATA

    ▲ Support Mini PCIe Expansion Slot (Including 6-pin SIM Card Slot

    ▲ Support 1*7Pin SATA slot

    ▲ Support 2*RJ45 1000m lan slot

    ▲ Support VGA/HDMI/LVDS display slot,Support Dual Display Synchronization

    ▲ Support Single 12V Power Input

    ▲ Support Windows7,Windows10 32/64bit system


    Model Name

    GW2-N19D VER:1.1

    Processor

    Intel Bay Trail-M/D Serial processor

    CPU

    J1900

    Memory

    Technology

    Singal DDR3L 1333MHz , max 8GB,1 x 204Pin DDR3L SO-DIMM(Non-ECC)

    Rear I/O

    Power slot

    1*standard 2.5mm DCpower slot

    HDMI

    Standard D slot,Support HDMI1.2,Max,resolution:2560*1600@60Hz

    VGA

    Standard DB15 slot,max Support resolution 2560*1600@60Hz

    Ethernet

    2*1000M lan, RTL8111H lan chipset

    USB slot

    2*USB slot (The USB 3.0 connector/header has a USB 2.0 slot located above it, and a USB 3.0 slot positioned below it. )

    Audio

    1*two-in-one slot (Line-out,Mic)

    Inner connector

    USB slot

    5*USB2.0slot

    COM slot

    2*(COM all Support RS232 mode,COM1 Support RS485 model)

    LVDSslot

    Support singal (dual)channel 18(24)bit,Max resolution 1920*1200@60Hz

    Audio Amplifier

    1*4Pin 2.0mm white slot , Support 2x5W 2Ω speakers

    Mini-PCIe

    1x Full-Length Mini PCIe Slot (Supports WIFI, 4G)

    MSATA

    Support SSD

    SATA slot

    1*7Pin SATAslot Support SATA 2.0

    GPIO

    8-channel bidirectional 5V

    Watchdog

    Output

    System Reset

    interval

    Programmable from 1 to 255 seconds

    Wattage

    Max wattage

    Standby Power Consumption: 9.6W
    Full Load Power Consumption: 30W

    Environment

    temperature

    work temperature:-10~70℃ moisture:5%~95% storage temperature:-40~85℃ moisture:5%~95%

    Form size

    size

    120 mm x 120 mm


    Quality Nano ITX Industrial Embedded Motherboard 12x12cm J1900 Fanless Mini Computer Mainboard for sale
