    AIO Motherboard Mini Itx HM86 Intel Gen4 I7 I5 I3 IMITX-IM48S-AIO-V1.1

    Ask Lasest Price
    Model Number : IMITX-IM48S-AIO-V1.1
    Delivery Time : 5-8 working Days
    Supply Ability : 10000pcs/Day
    • Product Details
    • Company Profile

    AIO Motherboard Mini Itx HM86 Intel Gen4 I7 I5 I3 IMITX-IM48S-AIO-V1.1

    AIO Motherboard mini itx HM86 Intel Gen4 i7/i5/i3 IMITX-IM48S-AIO-V1.1

    Features (product features)

    ▲ Support Intel Gen4 I7, I5, I3 series processors, rPGA947 socket.

    ▲ Support 1 SATA interface, 4 USB3.0 and 6 USB2.0.

    ▲ Support a single 206 Pin SO-DIMM to 8GB DDR3L 1600MHz.

    ▲ Supports 5.1-channel ALC887 chip.

    ▲ Support one serial port and RS232 and RS485 modes.

    ▲ The transmission speed of high-speed USB3.0 interface is improved again.

    ▲ Support onboard WIFI, M.2 expansion slot *2,

    ▲ RJ45 Gigabit NIC interface

    ▲ Support Win7 and Win10 32/64-bit operating systems.

    ▲ Support VGA/HDMI/LVDS display interface, and support synchronous three displays.


    Specifications (specifications)

    Model Name

    TMITX-IM48S-AIO VER:1.0

    processor

    Intel Gen4 i7/i5/i3 series processors

    Southbridge

    HM86 Chipset series

    memory

    technology

    Single channel DDR3L 1600MHz

    maximum capacity

    8GB

    Memory slot

    1*204Pin DDR3 SO-DIMM(Non-ECC)

    Post I/O

    DC interface

    1 standard 2.5mm DC power socket; 1 1x4 2.5mm small white socket

    HDMI

    Standard D socket, supporting HDMI1.4, maximum resolution: 2560*1600@60H.

    VGA

    Standard DB15 socket, the maximum supported resolution is 2560*1600@60Hz.

    Ethernet

    1 gigabit network card, RTL8111H network card chip.

    Audio

    1 (Mic-in, Line-out)

    USB port

    4 USB 3.0

    Internal connector

    USB port

    6 (one FUSB can transfer out two USB2.0 interfaces);

    serial port

    1 (serial port supports RS232 and RS485 modes)

    power amplifier

    1*4Pin 2.0mm small white socket, supporting two speakers of 5W2 Euro.

    LVDS interface

    Support single (dual) channel 18(24) bits, and the maximum resolution can reach 1920*1200@60Hz.

    JHDMI interface

    2*8Pin pin, supporting the maximum resolution of 2560*1600@60H(HDMI and JHDMI can only be selected).

    JVGA

    1*12Pin pin, the maximum supported resolution is 2560 * 1600 @ 60hz (VGA and JVGA can only be selected).

    M.2

    1 2240 slot with WIFI support.

    M.2

    1 full-length 2280 2260 M.2 slot, supporting NVME hard disk and SATA hard disk, optional by jumping cap.

    WIFI interface

    Support onboard WIFI (optional for customers)

    serial ata

    1 4PIN SATA power interface, supporting SATA 3.0

    PWR interface

    1 standard 1x4PIN power socket

    onekey recovery

    One 1*2Pin JRECO one-key restore interface (function to be developed)

    Watchdog

    output

    system reset

    space

    Programmable for 1 ~ 255 seconds

    power consumption

    Maximum power

    Standby power consumption: 16W Full load power consumption: 86W

    environment

    temperature range

    working environment

    Storage environment

    Temperature:-10 ~ 60℃ Humidity: 5%~95%

    Temperature: -40~85℃ Humidity: 5%~95%

    Physical size

    measure

    170 mm x 170 mm
