    GW7-T19D2E-V1.1 J1900 mini ITX industrial motherboard

    Ask Lasest Price
    Model Number : GW7-T19D2E-V1.1 J1900
    Delivery Time : 5-8 working Days
    Supply Ability : 10000pcs/Day
    • Product Details
    • Company Profile

    GW7-T19D2E-V1.1 J1900 mini ITX industrial motherboard




    Intel Atom Bay Trail-D/M Mini-ITX with VGA/2*EDP,6 COM,Dual LAN,MSATA,WIFI/4G Module,DDR3L,DC 12V Input


    Features (product features)

    Support Intel Bay Trail-M/D series processors.

    Support DDR3L memory, up to 8GB 1333MHz SDRAM.

    Support stereo dual-channel ALC887 chip with onboard power amplifier.

    Support 6 serial ports, 1 parallel port and 1 PS2 pin interface.

    Support 1 USB3.0 and 7 USB2.0.

    support MSATA

    Support Mini PCIE expansion slot (including 8pin SIM card slot)

    Support one 7Pin SATA interface.

    Support two RJ45 Gigabit network card interfaces.

    Support VGA/2*EDP display interface, and support synchronous dual display.

    Support single power supply 12V input.

    Support Windows7, Windows10 32/6



    Model Name

    GW7-T19D-2E VER:1.1

    processor

    Intel Bay Trail-M/D series processors

    CPU

    J1900

    memory

    technology

    Single channel DDR3L 1333MHz

    maximum capacity

    8GB

    Memory slot

    1 x 204Pin DDR3L SO-DIMM(Non-ECC)

    Post I/O

    power source

    1 standard 2.5mm DC power socket

    VGA

    Standard DB15 socket, the maximum supported resolution is 2560*1600@60Hz.

    Ethernet

    1 or 2 gigabit network cards (LAN1 and USB2.0 are laid together), RTL8111H network card chip.

    USB port

    2 USB interfaces (USB2.0 interface above USB3.0 cradle and USB3.0 interface below cradle)

    Audio

    1 (Mic-in, Line-out)

    Internal connector

    USB port

    6 USB2.0 interfaces (one FUSB can switch out two USB2.0 interfaces)

    PS2 interface

    1*7Pin 2.0mm white socket, which can connect PS2 keyboard and PS2 mouse.

    serial port

    6 (serial ports all support RS232 mode, among which COM2 and COM3 support RS422 and RS485 mode)

    parallel port

    1 2*13Pin pin

    JVGA

    1*12Pin pin, the maximum supported resolution is 2560 * 1600 @ 60hz (VGA and JVGA can only be selected).

    EDP interface

    Support two 4 LANE eDP channels, and support the maximum resolution of 1920x1200@60HZ.

    Audio

    1 2*5Pin pin (Mic-in, Line-out)

    power amplifier

    1*4Pin 2.0mm white socket, supporting 2 speakers with 5W2.

    Mini-PCIe

    1 Mini PCIe slot of full-length card (supporting WIFI and 4G modules)

    MSATA

    Support SSD hard disk

    serial ata

    1 7Pin SATA interface, supporting SATA 2.0

    GPIO

    8-way bidirectional 5V

    PWR interface

    1 standard 2x2PIN power socket

    Watchdog

    output

    system reset

    space

    Programmable for 1-255 seconds

    power consumption

    Maximum power

    Standby power consumption: 8.4W Full load power consumption: 25.2W

    environment

    temperature range

    working environment

    Storage environment

    Temperature:-10 ~ 60 Humidity: 5%~95%

    Temperature: -40~85 Humidity: 5%~95%

    Physical size

    measure

    170 mm x 170 mm
